FOCUS SAM² 6.7

Designed for down

• E-MTB für die härtesten Trails
• Downhill-Geometrie
• Aluminium-Rahmen in Carbon-Optik
• Bosch Performance Line CX E-Antrieb und Batterie mit 600 Wh oder 800 Wh, in allen Größen kompatibel mit dem 250 Wh-Range-Extender

Videos

Spezifikationen

• Charger
  • 625 Wh
• Brake
  • 220 mm
• Frame size
  • S,M,L,XL
  • 39,42,44,46
• Drive train
  • chain
• Max total weight
  • 150
• Frame
  • 7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. Gen2, 148x12 mm thru axle, internal cable routing, post mount 203 mm
• Fork
  • SR Suntour Durolux 38, RC2 29, 110x15 mm, 44 mm rake
• Handlebar
  • Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
• Saddle
  • Selle Royal Groove SRX
• Seat post
  • Post Moderne dropper post PM-214, 34.9 mm
• Stem
  • FOCUS C.I.S. 50 mm, 0°, 35 mm, aluminium
• Brakes
  • SRAM DB8, 4-piston, hydraulic disc brake,SRAM DB8, 4-piston, hydraulic disc brake
• Crank set
  • Samox EC40 ISIS
• Switch lever
  • SRAM SX Eagle, 12-speed
• Sprocket
  • SRAM PG-1230 NX Eagle, 12-speed
• Transmission
  • front: 36, rear: 11-50
• Headset
  • ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset
• Tyres
  • Maxxis Minion DHF, EXO, 29 x 2,5"
• Tyres, rear
  • Maxxis Minion DHF, EXO, 29 x 2,5"
• Wheel rims
  • RODI TRYP30, 30-622,RODI TRYP30, 30-622
• specs.ProductRearBrakeDescription
  • SRAM DB8, 4-piston, hydraulic disc brake
• Disc brake rotor, front
  • 220 mm
• Disc brake rotor, rear
  • 220 mm
• Battery
  • Bosch PowerTube Li-Ion
  • 625 Wh
• Display
  • Bosch LED Remote
• Motor
  • Bosch Performance Line CX Smart System, 85 Nm
• Colour
  • Rustorange,Rustbrown
  • Slategrey glossy,Magicblack glossy
  • Rustorange glossy,Rustbrown glossy
• Travel
  • 180 mm
• Hub
  • Novatec D041, 15x110 mm thru axle
  • Novatec D462, 12x148 mm
• Grip
  • Herrmans DD 41B
• Rear derailleur
  • SRAM NX Eagle, 12-speed
• Tire
  • Maxxis Minion DHF, EXO, 29 x 2,5"
• Shift/brake lever
  • SRAM SX Eagle, 12-speed
• Spoke
  • Niro, black
• Chain
  • SRAM SX Eagle, 12-speed
• Shock
  • Rock Shox Deluxe Select, 230/65 mm, hardware: 25,0 x 8.0 mm, no Bushing

Geometrie
